Containers becomes more common in the modern hospitals. Remeda´s handling systems for containers and instrument trays ease the work load for the personnel and reduces heavy lifting in difficult heights and positions.
At the same time it increases the efficiency with help of this complete system for handling containers and instrument trays from the sterilization department to the operating theatres.

This system creates the possibility for the staff to prepare the CUBE for each specific operation just-in-time.
The system include the rack called the CUBE, a lift to handle the rack and a transport unit.

Where the containers and instrument trays before had to be handled several times in a working cycle at
the hospital, today with help of the CUBE system they only have to be handled twice by personnel throughout the hospital.


The CUBE system handle the containers and instrument trays within the central sterilization department and operating department and the transportations in between.
The system consists of three parts, the shelf rack, transport trolley and lift trolley.

When lifting the container using the CUBE container
handling system it will always be done in the correct
lifting height thanks to the lifting trolley that is a part of the system.
The lifting trolley is both used in the central sterilization departments and in the operation department.
The container stays on the shelf rack from the packing table through the sterilizer, to the operation department and back to the central sterilization department.

When the transporter is transporting the racks it it covered with fabric to reduce the risk of contamination.

For further information about the products please contact Remeda »

Shelf racks

The shelf rack´s shelves can slide out which facilitate
easy lifting of the containers in its handles from the
correct lifting position.

The goods are put on the shelf rack after packing and the shelf rack is then easily handled with a lifting trolley.
When handling the goods using the CUBE system, it will always be done in the correct lifting height thanks to the lifting trolley that is a part of the system.

The lifting trolley is both used in the central sterilization
department and in the operation department.

The goods stays on the shelf rack from the packing table through the sterilizer, to the operation department and back to the central sterilization department.



Reference number Shelf rack mm (inch) Shelfsize mm (inch) Description

130 52-01 700x600x596
(27,6x23,6x23,5)
610x580x165
(24,0x22,8x6,5)
Removable shelves
130 52-02 700x600x596
(27,6x23,6x23,5)
610x580x165
(24,0x22,8x6,5)
Fixed shelves



Reference number Shelf rack mm (inch) Shelfsize mm (inch) Description

130 52-03 800x600x596
(31,5x23,6x23,5)
710x580x165
(28,0x22,8x6,5)
Internal use
130 52-04 800x600x596
(31,5x23,6x23,5)
710x580x165
(28,0x22,8x6,5)
Robot

Transport trolleys

The transport trolley is used to transport the CUBE between central sterilization department and the operation department.

The trolleys can be connected to each other in order to transport more cubes at a time.

There are several types of transport trolleys available, both open version and a trolley that is closed with stainless steel cover.

The lifting trolley is used to handle the cube within the central sterilization department.
With help of the trolleys, the cubes can be easily moved around and adjusted to the right working and lifting height for the personnel.

The transport trolley is developed to move goods between the departments in the hospital.
The transport trolley is specially designed to fit the customer need.
Transporting up to 6 containers or instrument trays.
The transport units can also be connected to each other to simplify the transportation.
There can be fitted a basket on top of the trolley where extra material can be placed.

Reference number Dimensions mm (inch) No. of Cubes Description
130 51-01 850x760x1600
(33,5x29,9x63,0)
2 Open
130 51-02 720x660x1130
(28,3x26,0x44,5)
1 Open
130 51-03 860x760x1700
(33,9x29,9x66,9)
2 Closed
Reference numberHeight mm (inch)Capacity kg/lbs
130 56-01454-854 (17,9-33,6)150 (330)
Reference number Shelf rack mm (inch) Shelf size mm (inch)
130 53-01 800x600x1220
(31,5x23,6x48,0)
710x580x235
(28,0x22,8x9,3)

Lift trolley

The lifting trolley is used to handle the CUBE within the central sterilization unit and in the operation department.
With help of the lift, the cubes can be easily moved around and adjusted to the right working and lifting height for the personnel.

Reference numberHight mm (inch)Capacity kg/lbs
130 50-01190-990 (7,5-39)90 (198)
130 50-02450-950 (17,7-37,4)90 (198)

Washroom trolley

The washroom trolley is used to handle the CUBE in the central sterilization department.
With help of the trolley, the cube and the transport trolley can easily be moved around in the washing area.
With help of the washroom trolley the goods will be adjusted to the correct working and lifting height for the personnel.

Reference numberHeight mm (inch)Capacity kg/lbs
130 55-01305-555 (12,0-21,9)150 (330)

Storage system
